Features and Specification FEATURES Tuner Memory Presets: Preset Stations (FM:12 / AM:6) Memory: Auto Memory Seek Mode: Local / DX Seek Selectable Bluetooth® Bluetooth Module Built-In: Bluetooth Module Built-In Hands Free Calling: HFP (Hands Free Profile), HSP (Head Set Profile) Compatible Phones Music Streaming: A2DP (Advanced Audio Distribution Profile) Music Streaming Control: AVRCP (Audio/Video Remote Control Profile) Ver.1.3 Compatible BT Plus Advanced Bluetooth Technology: BT Plus Advanced Bluetooth Technology Connection: SSP (Secure Simple Pairing) Supported Phone Book: Phone Book Synchronization Phone Book Search: 3 Letters Alphabet Search Shortcut Dialing: 6 Presets Memory Multiple Phone Number Registration: 3 Phone Number Registration Possibility Voice Dial Operation: Voice Dial Operation Auto Answer: Auto Answer Call History: Dialled Call, Received Call, Missed Call Speech Volume Level Adjustment: Adjustable for Outgoing and Incoming Volume Hands-free Phone Sound Setting: 5 Type Selection Bluetooth Audio Sound Adjustment: Media Xpander® Phone Battery Level Indicator: Phone Battery Level Indication Phone Signal Strength Indicator: Phone Signal Strength Indication Firmware Update: Firmware Updatable Microphone: Microphone Included Connection for iPod® Compatibility for iPod®/iPhone®: Made for iPod touch 4th/3rd/2nd/1st Gen., iPod nano 6th/5th/4th/3rd/2nd/1st Gen., iPod classic 160GB/120GB/80GB, iPod with video, iPhone 4S, iPhone 4, iPhone 3GS, iPhone 3G and iPhone Connection: KCU-445i (sold separately) Required Available Selections: Playlist, Artist, Album, Song, Podcast, Genre, Composer, Audiobook, Genius Alphabet Search: Alphabet Search Percentage Search: Percentage Search Direct Up/Dn: Playlist, Artist, Album, Genre, Composer, Episode Up/Down App Direct Mode: App Direct Control Direct iPod/iPhone Control: M.I.X. (Shuffle) Capability: Song, Album, All Repeat: Repeat Battery Charging: Battery Charging Connection for USB USB Connection: Front USB Connection Music File Playback: MP3/WMA File Playback USB Class: Mass Storage Class File/Folder Name Search: File/Folder Name Search Percentage Search: Percentage Search Folder Up/Down: Folder Up/Down M.I.X. Random Play: M.I.X. Random Play Repeat: Repeat Satellite Radio SiriusXm Ready: Preset Memory: 3x6 Music Information: Category, Artist, Song My Game / My Music Alert: Instant Replay: iTunes® Tagging: Disc Player Disc Type: CD Player Disc Playback Type: CD, CD-R/RW Music Playback: CDDA, MP3/WMA CD Text Display: CD Text Display CD Text Search: CD Text Search M.I.X. Random Play: M.I.X. Random Play Repeat: Repeat DAC: Multi Bit DAC Digital Servo: Display Servo Sound Tuning Subwoofer Level: Subwoofer Level Adjustment Subwoofer Phase Select: Subwoofer Phase Adjustment Subwoofer System Select: Subwoofer Level Control Management High Pass Filter: High Pass Filter Low Pass Filter: Low Pass Filter 3-band Parametric Equalizer: 3-band Parametric Equalizer Bass Level: Bass Center Frequency: Bass Bandwidth Adjustment: Mid Level: Mid Center Frequency: Mid Bandwidth Adjustment: Treble Level: Treble Center Frequency: Treble Bandwidth Adjustment: MediaXpander: Media Xpander® Source Tone Memory: Source Tone Memory General Power Output: Max. 50W x 4 High Power Amplifier Display: 13 Segments White LCD Display Control Type: Rotary Encoder Knob Illumination Buttons: Blue Illumination Buttons High Grade Audiophile Design: High Grade Audiophile Design AUX Input: Front AUX Input (3.5mm mini jack) PreOut: 2 PreOuts (2V, Front + Rear/Subwoofer) Steering Wheel Remote Control: Steering Wheel Remote Control Ready Remote Control Ready: Remote Control Ready Clock: Clock Function DIN Trim Plate: Detachable Trim Plate Detachable Face Plate: Detachable Face Plate Dimmer: Dimmer Input Power Antenna Lead: Power Antenna Output Remote Turn-On: Remote Turn-On Output SPECIFICATIONS CEA-2006 Power Ratings CEA-2006 Power Rating: 18W RMS x 4, 4ohms @ 14.4V, =1% THD+N, S/N 80 dBA (ref. 1W) Max Power Output Ratings Max Power Output: 50W x 4 FM Tuner Tuning Range: 87.7 - 107.9 MHz Mono Usable Sensitivity: 9.3 dBf (0.8 µV / 75 ohms) 50dB Quieting Sensitivity: 13.5 dBf (1.3 µV / 75 ohms) Alternate Channel Selectivity: 80 dB Signal-to-Noise (S/N) Ratio: 65 dB Stereo Separation: 35 dB Capture Ratio: 2 dB AM Tuner Tuning Range: 530 - 1,710 kHz Usable Sensitivity (IEC Standard): 22.5 µV / 27 dB Bluetooth® Bluetooth Version: Bluetooth V3.0 Output Power: +4 dBm Max. (Power Class 2) HFP: Hands Free Profile HSP: Head Set Profile A2DP: Advanced Audio Distribution Profile AVRCP: Audio/Video Remote Control Profile v1.3 Disc Player Frequency Response: 5 - 20k Hz (±1 dB) Channel Separation (at 1kHz): 85 dB Dynamic Range (at 1kHz): 95 dB Total Harmonic Distortion (at 1kHz): 0.008 % Wow & Flutter (%WRMS): B.M.L. Signal-to-Noise Ratio: 105 dB Connection for USB USB Requirements: USB 1.1/2.0 Max. Power Consumption: 1,000 mA USB Class: Mass Storage Class File System: FAT 12/16/32 MP3 Decoding: MPEG AUDIO Layer-3 WMA Decoding: Windows Media™ Audio Number of Channels: 2-Channel (Stereo) Frequency Response: 5 - 20k Hz (±1 dB) *May differ depending on the encoder software/bit rate. Total Harmonic Distortion (at 1kHz): 0.008 % Dynamic Range (at 1kHz): 95 dB Signal-to-Noise Ratio: 105 dB Channel Separation (at 1kHz): 85 dB Sound Tuning Subwoofer Level Adjustment: 0 to +15 Subwoofer Phase Setting: 0° or 180° High Pass Filter: Off, 60/80/120/160 Hz Low Pass Filter: Off, 60/80/120/160 Hz Bass Level Control Range: -14 to +14 dB Bass Center Frequency: 60/80/100/120 Hz Bass Band Width Adjustment (Q): 4 choices (0.5=wide, 1.0=medium, 1.5=medium, 2=narrow) Mid Level Control Range: -14 to +14 dB Mid Center Frequency: 500/1k/1.5k/2.5k Hz Mid Band Width Adjustment (Q): 4 choices (0.75=wide, 1.0=medium, 1.25=medium, 1.5=narrow) Treble Level Control Range: -14 to +14 dB Treble Center Frequency: 7.5k/10k/12.5k/15k Hz Treble Band Width Adjustment (Q): 2 choices (0.75=wide, 1.25=narrow) Dimensions Din Size: 1 DIN Chassis Size (W x H x D) mm: 178 x 50 x 161 mm Chassis Size (W x H x D) in: 7' x 2' x 6-3/8' Nose Piece Size (W x H x D) mm: 170 x 46 x 25 mm Nose Piece Size (W x H x D) in: 6-3/4' x 1-13/16' x 1' General Power Requirement: 14.4 V.DC (11-16V allowable) Pre Output Voltage (Before Clipping): 2V / 10k ohms Aux-In: 1.4V / 10k ohms Maximum Mounting Angle: 35° Weight: 1.5 kg (3 lbs. 4 oz) Recommended Accessories KTP-445U: Universal Head Unit Power Pack RUE-4202: Wireless Remote Control KCU-445i: USB Connection for iPod/iPhone KCU-230NK: KCE-220UB: USB Extension Cable
