AtlasIED FAP42T-UL2043
AtlasIED FAP42T-UL2043 0
AtlasIED FAP42T-UL2043 1
AtlasIED FAP42T-UL2043 2

AtlasIED FAP42T-UL2043

Model #: FAP42T-UL2043
557238
AtlasIED
At a Glance
4" COAXIAL IN-CEILING SPEAKER WITH 16-WATT 70/100V TRANSFORMER, PORTED ENCLOSURE, AND UL2043 CERTIFICATION
Available in Store Only
$150.00Save $NaN
$150.00

Get to know this product.

Description

The FAP42T-UL2043 from AtlasIED meets requirements of UL 2043 for speakers used in air handling (true plenum) spaces. FAP42T-UL2043 combines superior coaxial speaker performance with wide dispersion and easy installation.

A low profile enclosure and wide coverage make the FAP42T-UL2043 a perfect choice for low ceilings.

The FAP42T-UL2043 will satisfy the needs of owners, architects, contractors, and consultants by delivering true, high fidelity sound reproduction in an attractive and easy-to-install system.

The FAP42T-UL2043 is ideal for high-intelligibility voice, music, and signal reproduction in commercial, industrial, and institutional applications.

Features

  • 4 Pole Detachable "Phoenix" Style Connector Allows Easy Pre-Wiring and is Convenient for Daisy Chaining Additional Strategy Full Range Speakers or Subwoofers
  • Easy Installation in Drop Tile or Sheetrock Ceilings via C-ring/V-rail Tile Bridge and "Dog Leg" Mounting System (Included)
  • Enhanced Quality 70.7V/100V Internal Transformers Minimize Insertion Loss and Maintain Low Frequency Response While Providing increased Output for Higher SPL Applications
  • Extended Low Frequency Response from the 285 Cubic Inch Optimally Tuned and Ported Deep Drawn Galvanized Steel Enclosure
  • Front Mounted Tap Selector Switch for Easy System Tuning Adjustments Includes Transformer Bypass Setting for 8 ohm Direct Coupled Operation
  • Perfect Companion with the FAPSUB Subwoofer System When Sub Bass is Required
  • Press-Fit Grille Blends Perfectly into Contemporary Architecture

Applications

The FAP42T-UL2043 combines superior coaxial loudspeaker performance with wide dispersion and easy installation. A low profile enclosure and wide coverage make the FAP42T-UL2043 a perfect choice for low ceilings. The FAP42T-UL2043 will satisfy the needs of owners, architects, contractors, and consultants by delivering true, high fidelity sound reproduction in an attractive and easy-to-install system. The FAP42T-UL2043 is ideal for high-intelligibility voice, music, and signal reproduction in commercial, industrial, and institutional applications. The FAP42T-UL2043 is UL1480 and UL2043 listed allowing for installation in true plenum air spaces.

Specifications

More Info

Speaker TypeCoaxial
Sensitivity88dB Average
Power Taps1, 2, 4, 8, 16 Watts & 8O
Dispersion130°
Power Rating25 Watts (8O)
Frequency Response75Hz – 20kHz (±7dB)
Woofer4" Poly Cone with Butyl Rubber Surround
Magnet Weight10oz (364g)
Enclosure Volume285 in3
HF DriverCoaxially Mounted PEI Dome Tweeter
Diameter10 1/2" (267mm)
Overall Height8 7/8" (225mm)
Cut-Out Diameter9" (229mm)

Misc. Specs

ColorWhite
Depth (in.)8 7/8
